The M84 is a versatile, race-bred ECU that is suitable for a broad range of high performance applications, including engines with up to 8 cylinders. It also suits rotary engines with twin, triple or quad rotors.

This new, entry level ECU is based on the advanced technology in MoTeC's benchmark M800, with a package of features to suit more moderate system requirements. It includes on-board Wideband Lambda plus 1MB of data logging memory as standard.

Now with Nitrous Injection and 100 Hz max logging rates!

Install it as a stand-alone ECU or as part of a complete motorsport-ready engine management and data acquisition solution.

BASIC SPECIFICATIONS

Outputs

• 8 x Injector outputs - high or low ohm
• 6 x Ignition outputs
• 8 x Auxiliary outputs - for functions such as boost control, idle speed stepper motor and many more

Inputs

• Throttle Position
• Manifold Pressure
• Mass Air Flow
• Fuel Pressure
• Oil Pressure
• Exhaust Temperature
• Gear Position
• User 1
• Air Temperature
• Coolant Temperature
• User 2
• 3 x Switched Analogue Temperature
• 2 x Lambda Inputs (supports Wideband and Narrowband sensors)
• 4 x Digital Inputs (wheel speed or switch)

Communications

• 1 x CAN
• 1 x RS232

Physical

• Case size 147 x 105 x 40 mm
• Weight 500 grams
• 1 x 34 pin and 1 x 26 pin waterproof connector with gold plated contacts
